  Mainsail -




5000511 Nadia












M0




Sail Layout




Layout R0















M1




Tack
  Cut Back (Aft face of Mast to center of tack Pin

- A)




65mm






HELP







M2




Tack Cut Up (Top of Boom to Center of tack Pin - B)




55mm




HELP







M3




Clew Cut Up (Top of Boom to Center
  of Tack Pin - X)




50mm




HELP







M4




Clew type (slug, outhaul car or ring with strap)




Outhaul
  car




HELP







M5




Sunbrella
  clew cover for Furling Mains




na




HELP







M6




Other Offsets









HELP







M7




Headboard




Yes




HELP







M8




Leech Line




yes












M9




Foot Line




No












M10




Tack Ring Type




#2




HELP







M11




Tack angle




88.5




HELP







M12




Jack Line




No




HELP







M13




Mast Bend
  (Luff Round)




Std




HELP







M14




Fractional Rig (Yes, No)




No




HELP







M15




Mast
  - Keel or Deck Stepped?




Deck step












M16




Number of Reefs




3 Reefs




HELP







M17




Intermediate
  Reefing Diamond Eyes
  (Yes or No)




Yes




HELP







M18




Foot Reefing
  Grommets (next to boom)




N/A




HELP







M19




Reefing
  Ring Type




#1




HELP









M20






Luff Length (Max
  Hoist - P)




13.000mm Max

(12.87m Net Finished size day of Delivery)






HELP











M21






Foot Length (Max Foot - E)




4500mm
  Max

4.455m (Net Finished size day of Delivery)






HELP







M22




Leech Length (straight line
  head to clew)




Sailmaker




HELP







M23




Bimini to Clear
  (yes or no)









HELP







M24




Foot Round




Sailmaker












M25




Aspect Ratio




Sailmmaker




HELP







M26




Vessel Backstay Measurement




5890mm




HELP



















M27
















Luff Slides (Part
  Number)




A008


























HELP



















M28
















Foot Slides (Part
  Number)




A018S


























HELP







M29




Roach Type




Cruise




HELP







M30




Roach Factor




1.1




HELP









M31




MGM




Sailmaker




HELP







M32




MGU




Sailmaker




HELP







M33




Batten Type (Partial or Full)




4 Full




HELP







M34




Include Battens




N/A












M35




Install Nylon Batten Holders




YES




HELP









M36






Intermediate Sliders




YES



2






HELP









M37






Cloth Weight




9.18oz Challenge Performance Cruise - Cross Cut












M38




Cut Type




Cross












M39




Sail Area




Sailmaker












M40




Cunningham




No




HELP







M41




Telltails




Yes




HELP







M42




Triple Stitch




Yes












M43




Sail Logo and Color(red, blue
  or black)




No




HELP







M44




Sail Logo
  Artwork




N/A












M45




Sail Numbers and Color




No




HELP







M46




Draft Stripe and Color(red, blue or black)




Yes BLUE




HELP







M47




Overhead
  Leech Line




No












M48




Specialty Sail




No




HELP







M49




Boom Cover




Yes




HELP







M50




Lazy Bag




No




HELP





















- Headsail -




5000511
  Nadia












H0




Sail Layout




Layout R0













H1




Size of Headsail (110, 135,

150 etc.)"




130%




HELP







H2




Luff
  Length, Max Hoist, B measurement




webbing loop tip to webbing loop




HELP


















14.50m tip (Max)



(14.355m Net Finished size day of delivery)












H3




Leech Length




sailmaker




HELP







H4




Foot Length




sailmaker




HELP







H5




Tack and Head Fittings




Webbing Loops












H6




Clew Type (Press ring or 0- Ring)




Press Ring




HELP







H7




Leech Line




Yes












H8




Reefs for Hank on
  Sail (specify Qty
  of tiedowns)




No Manual Reefs












H9




Foot Line




Yes












H10




Track 1 (Tack to Genoa Track Beginning)




6000mm




HELP







H11




Track
  2 (Tack to Genoa Track Ending)




8300mm




HELP







H12




Vessel
  "I" Measurement




14.68m




HELP







H13




Vessel "J" Measurement




4.77m




HELP







H14




Calculated Forestay Length




Sailmaker












H15




Reef




N/A












H16




LP




Sailmaker




HELP









H17






Color of Suncover




Sapphire
  TWD CWM 396






HELP







H18




Side of Sail for
  Suncover (port or Stbd)




PORT














H19






Luff Tape Size (such as #6)




5mm






HELP







H20




Furler Manufacturer




Profurl
  C350












H21




Foam Luff




Yes




HELP







H22




Cut Type




Cross












H23




Sail Area




Sailmaker












H24




Telltails




Yes




HELP







H25




Telltail Window




No














H26




Triple
  Stitch




YES












H27




Logo




No




HELP









H28






Cloth Weight




9.18oz Challenge Performance Cruise

- Cross Cut












H29




Sail
  Numbers and Color (red, blue or black)




No




HELP







H30




Sheeting Stripe (red, blue, black)




No




HELP







H31




Draft Stripe Color (red,
  blue or black)




Yes BLUE




HELP







H32




Clew Height off
  Deck




sailmaker




HELP







H33




Tack Height off
  Deck




460mm




HELP







H34




Luff tape starts 460mm
  up from Tack




460mm




HELP







H35




Specialty Sail




No




HELP












Customer Note: All
  details we can check as sailmakers
  are based on accurate vessel I and J Measurements









HELP







Boom cover v1
