Order Number : 5000226 Claudia
Vessel       : Comfortina 35

Deposit
Recv'd
 Measurements
Complete
 Layouts
Requested
 Layouts
Posted
 Waiting for
Approval
 Layouts
Approved
 Order in
Production
 Order
Completed
 Customer
Advised
 Order
Shipped
XXXXX










Special Shipping Instructions : None

 Sail as Quoted to Customer:


Performance Mainsail - Tri Radial Cut
3x Reefs + „Comfortina 35“ Logo in blue on both sides + Numbers in blue (GER 138) on both sides
4x Full Battens Pockets
4x Battens
4x Ronstan Batten Holders RONSTAN RC00110 Batten receptacles with M10 thread for Ronstan Series 6 battencar RON-RC 26166,
Intermediate bushings Ronstan Bush, Suits 13mm (1/2) Webbing, (Suits Cars RC26163) for Ronstan Series 6 Ballslide Intermediate Car, 55mm x 41mm RON-RC26163 Draft Stripe, Telltails, Triple Stitched
Sailbag
Aluminum Headboard that fits Ronstan Series 6 Ballslide Headboard Car, 160mm x 41mm (RONRC26160)
Leech line, Cam Cleat
Radial Patches Head, Clew and Tack
Ronstan Sail Bushings included see above, no Sail slides or slugs!!!
Full Standard Roach 1.10 (110%)
P:13.25m E:4.45m
Sail Area : 32.42m2
Sailcloth : DP - DCX - Tri Radial (laminate like CDX)


Battens


Lazy Bag Sailcover for above mentioned mainsail and specification made from Challenge Sailcloth in Oyster colour CWM423.




How to Use This Web Based Order Form


Customer Information

=== CUSTOMER BILLING INFORMATION ===

Transaction ID: 26U35838YP4249705


Phone             :
E-Mail            : cuhrig007@web.de


USE: claudia.busseuhrig@viva-maris.de


==== CUSTOMER SHIPPING INFORMATION ===


Claudia Uhrig
SIEGRUNWEG 23
22559 HAMBURG
Germany


Quote Number       :316319963.TXT
ID                 :132159921.TXT

Cunningham 40USD
Sail Specifications

x
x








 - Mainsail -

5000226 Claudia

M0

Sail Layout

Layout R0

M1

Tack Cut Back (Aft face of Mast to center of tack Pin - A)

80mm

M2

Tack Cut Up (Top of Boom to Center of tack Pin - B)

20mm

M3

Clew Cut Up (Top of Boom to Center of Tack Pin - X)

45mm

M4

Clew type (slug, outhaul car or ring with strap)

Press Ring

M5

Sunbrella clew cover for Furling Mains

na

M6

Other Offsets

M7

Headboard

Yes

Headboard to fit



RON-RC26160

M8

Leech Line

yes

M9

Foot Line

YES

M10

Tack Ring Type

Press Ring – SR20

M11

Tack angle

88.5

M12

Jack Line

No

M13

Mast Bend (Luff Round)

Std

M14

Fractional Rig (Yes, No)

Yes

M15

Mast - Keel or Deck Stepped?

Keel

M16

Number of Reefs

3  Reefs

M17

Intermediate Reefing Diamond Eyes (Yes or No)

Yes, with 2 Eyelets for each reefing

M18

Foot Reefing Grommets (next to boom)

N/A

M19

Reefing Ring Type

Webbed ring for the luff with inside diameter 30mm,


Luff:

1st webbed ring on starboard side,
2nd webbed ring on portside,
3rd webbed ring on starboard side.



Leech to have press Ring

M20

Luff Length (Max Hoist - P)

13.25m  Max

(Net Finished size day of Delivery)

M21

Foot Length (Max Foot - E)

4.450m  Max

(Net Finished size day of Delivery)

M22

Leech Length (straight line head to clew)

Sailmaker

M23

Bimini to Clear (yes or no)

N/A

M24

Foot Round

Sailmaker

M25

Aspect Ratio

Sailmaker

M26

Vessel Backstay Measurement

N/A

M27

Luff Slides (Part Number)





M28

Foot Slides (Part Number)

Loose Footed

M29

Roach Type

1.1

M30

Roach Factor

110

M31

MGM

Sailmaker

M32

MGU

Sailmaker

M33

Batten Type (Partial or Full)

4 Full

M34

Include Battens

Yes

M35

Install Nylon Batten Holders

M36

Intermediate Sliders

2 between each batten

Webbing for bushing





2 between each batten, webbings for bushing,
Ronstan bush Art No. 00021 must be sewn into the webbing for the Ronstan intermediate cars RC26163that suits 13mm (1/2“) webbing.

M37

Cloth Weight

DCX-M

M38

Cut Type

Tri Radial

M39

Sail Area

M40

Cunningham

Yes

M41

Telltails

Yes

M42

Triple Stitch

Yes

M43

Sail Logo and Color(red, blue or black)

Yes


Comfortina 35 logo (blue)

M44

Sail Logo Artwork

N/A

M45

Sail Numbers and Color

Yes

GER 138 (blue)

M46

Draft Stripe and Color(red, blue or black)

Yes (Blue)

M47

Overhead Leech Line

No

M48

Specialty Sail

No

M49

Boom Cover

No

M50

Lazy Bag

Yes


Oyster
